Pressure Sensors Fluid


Pressure Sensor Fluid PSC-10

  • Application: 0 to 10 bar
  • Response time: 1.5 ms (5 V Variant) or 1 ms (12 V Variant)
  • Pressure reference type: Absolut
  • Power supply: 5 or 12 V
  • Weight: 45 g

Pressure Sensor Fluid PSC-260

  • Application: 0 to 260 bar
  • Response time: 2 ms
  • Pressure reference type: Absolut
  • Power supply: 5 V
  • Weight: 35 g

Pressure Sensor Fluid PSM-SA

  • Application: 0 to 3.5, 6, 10, 20, 35, 60, 70, 100, 200, 350, 700 bar
  • Response time: 1 ms
  • Pressure reference type: Absolut
  • Power supply: 8 to 30 V
  • Weight: 13 g

Pressure Sensor Fluid PSS-10

  • Application: 1 to 11 bar
  • Response time: 1.5 ms
  • Pressure reference type: Absolut
  • Power supply: 5 V
  • Weight: 45 g

Pressure Sensor Fluid PSS-250R

  • Application: 0 to 250 bar
  • Response time: 1.5 ms (5 V Variant) or 1 ms (12 V Variant)
  • Pressure reference type: Relative
  • Power supply: 5 to 12 V
  • Weight: 45 g

Pressure Sensor Fluid PSS-140/260/420/600

  • Application: 0 to 140, 260, 420, 600 bar
  • Response time: 2 ms
  • Pressure reference type: Absolut
  • Power supply: 5 V
  • Weight: 35 g
